Instruction:
Jingjiang ACEPOM instrument is professional in designing, producing and saling of induction bearing heaters. The ZNW series induction bearing heater, mainly sued for heating metal bearings, gears, bushings, bushing rings, pulley, etc. various types of connectors, through heating can be expanded to achieve a assembly needs. With heat sink design, better heat dissipation.
Features:
1. Automatical power regulation and demagnetization;
2. Environmental protection, no soot pollution;
3. An assembly solution with good quality, time and power saving;
4. Reliable and easy operation without fire danger.
Catalogue and parameters:
| Model | ZNW-2 | ZNW-3.6 | ZNWX-3.6 | ZNW-8 | ZNW-12 | ZNW-24 |
| Power (KVA) | 2 | 3.6 | 3.6 | 8 | 12 | 24 |
| Voltage (V) | 220 | 220 | 220 | 380 | 380 | 380 |
| Electric current (A) | 9 | 16 | 16 | 22 | 32 | 63 |
| Frequency (Hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| bearing ID Ø: mm (mm) | 30-100 | 30-160 | 30-160 | 30-300 | 70-400 | 70-600 |
| Max. bearing OD Ø: (mm) | 210 | 480 | 480 | 500 | 700 | 900 |
| Max. bearing width: (mm) | 115 | 150 | 150 | 200 | 265 | 265 |
| Operating area (w x h) (mm) | 145*120 | 140*170 | 140*170 | 200*200 | 265*280 | 265*280 |
| Maximum weight (Kg) | 30 | 45 | 65 | 95 | 150 | 170 |
| Standard yokes (mm) | 20,30 | 20,30,40 | 20,30,40,60 | 20,30,40,70 | 40,50,80 | 40,50,90 |
| Dimensions (w x d x h)(mm) | 330×330×345 | 330×330×345 | 330×330×355 | 390×330×465 | 900×500×850 | 900×530×860 |
| Weight (Kg) | 17 | 20 | 35 | 65 | 100 | 150 |
| Horizontal heating bracket | optional | optional | optional | optional | optional | optional |
| Temperature control | Max.250°C |
| Control mode | Temperature control, hand control |
| Temperature display | digital display |
| Magnetic temperature measuring probe | yes |
| Automatic power regulation | yes |
| Automatic demagnetization | yes |
